TengTools | Item ID:
3492P1000
3/4" Torque Wrench Plus 200 - 1000Nm
- 3/4″ torque wrench Plus
- ±4% accuracy
- 72-teeth ratchet mechanism with 5° swing arc
- Click-type mechanism with audible and tactile signal
- Quick-release button and twist reverse function
- Locking button to secure torque setting
- Clear Nm scale with 2.5 Nm resolution
- Ergonomic bi-material grip
- Delivered in a protective storage case
- Individually tested to ISO 6789 standards with unique serial number and Declaration of Conformance
Warranty
Warranty
Documents
Description
Description
TengTools 3492P1000 3/4″ torque wrench Plus provides precise torque control, offering a range of 200–1000 Nm with a reliable accuracy of ±4%. It is particularly suited for securing high-torque fasteners on large machinery and equipment where safety and reliability depend on accurate torque settings. It features a durable 72-tooth quick-release ratchet mechanism, supporting right-hand fastening with twist reverse functionality. Designed for comfort and efficiency, the wrench’s ergonomic bi-material grip and compact head allow for easy handling in tight spaces, making it suitable for demanding operations. A secure locking button ensures the torque setting remains stable during critical tasks. With a scale resolution of 5 Nm, the tool allows for precise torque adjustments. Weighing 5900 g and measuring 66 mm in width and 1243 mm in length, the wrench is engineered for durability and consistent professional performance. A robust storage case for safe transport and storage is included. Each torque wrench is assigned a unique number and individually tested to comply with ISO 6789 standards and comes with a ‘Declaration of Conformance’ for guaranteed accuracy.
Designed in Sweden
| Attribute | Value |
|---|---|
| Product Type | Torque Wrenches |
| Drive | 3/4" |
| No. of teeth | 72 |
| Primary scale resolution | 5 |
| Accuracy | ± 4% |
| Conformance certificate | Factory |
| Reverse direction | Twist |
| Mechanism | Click |
| Effective length (mm) | 1133 |
| Standard | DIN 3122;ISO 6789 |
| Width (mm) | 66 |
| Item weight (g) | 5900 |
| Primary range | 200-1000 Nm |
| Length | 1243 mm |
